Color: Blue, Beige(Optional)
Charging Type: USB charging
Maximal Sound Output: 118dB ± 4dB
Frequency Range: 400Hz-3800Hz
Equivalent Input Noise Level: ≤ 30dB
Input Voltage: AC110-220V
Output Voltage: DC5V
Rated Power Supply Current Consumption: ≤ 2mA
bluetooth Open Method:
After booting, press and hold the M button for about 3 seconds to hear a very clear sound, then the indicator light is blue that means the bluetooth function is turned on.
Bluetooth Connection Method:
Turn on the bluetooth function of the mobile phone, enter the bluetooth search interface of the mobile phone system (or other smart device with bluetooth function), find the name of the bluetooth device of ZTQ and click the connection. After the connection is successful, there will be a voice prompt for successful pairing of “”Pairing successfully””.
1. When a call comes in, press the M button to answer or hang up, and press and hold for 2 seconds to disconnect.
2. When playing music, short press the M button to pause or resume playback.
3. If there is no sound signal for 10 seconds, the machine will automatically exit bluetooth mode to enter the hearing aid mode and exit the bluetooth connection after a period of time.
1x Voice Sound Amplifier Device (High Quality Box Package)
1x USB Cable
1x User Manual
When the battery is low, the bluetooth function will not be used, but the sound amplifier can work normally, because the power consumption of the sound amplifier is smaller, so please charge it when the bluetooth function is not used.
1. Do not remove or replace the built-in lithium battery
2. The power adapter and the main unit have a certain amount of heat during the charging process, which is normal.
3. Charge for at least 4 hours at the first time, and then use out completely . After three consecutive times, the battery can be used optimally.
